Wedge Wire Screens & Rotary Screens

Bar Screens

Continenetal manufacturers Wedge Wire Screens to suit a wide variety of applications such as Sugar, Coal, Mining & Quarrying Mineral Processing, Cement etc. The screens are made of the quality wedge wire in various grades of stainless steel.





Looped Wire Screens

Extremely effective for static separation and dewatering. The wedge screens consist of conical section wire arranged in rows with loops, which bind them on round cross bar. The opening between the wires form a conical slit for free and easy separation. Due to this special wedge profile clogging is prevented.



Type:	Fine & Wide Slit Screens
Profile:	22; 28 & 34
Cross Rod:	Dia 7.6 mm, 10mm, 12mm etc.
Material:	Stainless Steel AISI-304 & AISI-316 with end bars of carbon steel or AISI-304
Slit Width:	0.2mm and above



Welded Wedge Wire Screens

Consists of conical section wires resistance welded on to special cross bars. This provides a straight and continous, uninterrupted slots for free and easy flow. The feed is evenly distributed over the entire screen area, resulting in higher open area and increased life.



Type:	Fine Slit Screens
Profile:	22; 28
Cross Rod:	6.5 etc.
Material:	Stainless Steel AISI-304 & AISI-316. End bars of carbon steel or AISI-304. Other materials available on request.
